Public Member Functions | |
~TauolaHEPEVTParticle () | |
TauolaHEPEVTParticle (int pdgid, int status, double px, double py, double pz, double e, double m, int ms, int me, int ds, int de) | |
void | undecay () |
void | setMothers (std::vector< TauolaParticle * > mothers) |
void | setDaughters (std::vector< TauolaParticle * > daughters) |
std::vector< TauolaParticle * > | getMothers () |
std::vector< TauolaParticle * > | getDaughters () |
void | checkMomentumConservation () |
TauolaHEPEVTParticle * | createNewParticle (int pdg_id, int status, double mass, double px, double py, double pz, double e) |
bool | isDaughterOf (TauolaHEPEVTParticle *p) |
bool | isMotherOf (TauolaHEPEVTParticle *p) |
void | print () |
void | setPdgID (int pdg_id) |
void | setStatus (int statu) |
void | setMass (double mass) |
int | getPdgID () |
int | getStatus () |
double | getMass () |
double | getPx () |
double | getPy () |
double | getPz () |
double | getE () |
void | setPx (double px) |
void | setPy (double py) |
void | setPz (double pz) |
void | setE (double e) |
int | getBarcode () |
void | setBarcode (int barcode) |
void | setEvent (TauolaHEPEVTEvent *event) |
int | getFirstMotherIndex () |
int | getSecondMotherIndex () |
int | getDaughterRangeStart () |
int | getDaughterRangeEnd () |
TauolaParticle * | clone () |
double | getAngle (TauolaParticle *) |
void | add (TauolaParticle *) |
void | subtract (TauolaParticle *) |
void | decay () |
void | addDecayToEventRecord () |
int | getSign () |
double | getPolarimetricX () |
double | getPolarimetricY () |
double | getPolarimetricZ () |
bool | hasDaughters () |
TauolaParticle * | findLastSelf () |
std::vector< TauolaParticle * > | findProductionMothers () |
void | boostToRestFrame (TauolaParticle *boost) |
void | boostDaughtersToRestFrame (TauolaParticle *boost) |
void | boostFromRestFrame (TauolaParticle *boost) |
void | boostDaughtersFromRestFrame (TauolaParticle *boost) |
void | boostAlongZ (double pz, double e) |
void | rotate (int axis, double phi, int second_axis=Z_AXIS) |
void | rotateDaughters (int axis, double phi, int second_axis=Z_AXIS) |
double | getRotationAngle (int axis, int second_axis=Z_AXIS) |
double | getP () |
double | getP (int axis) |
void | setP (int axis, double p_component) |
virtual void | decayEndgame () |
Static Public Attributes | |
static const int | SAME_SIGN = 1 |
static const int | OPPOSITE_SIGN = 2 |
static const int | NA_SIGN = 3 |
static const int | STABLE = 1 |
static const int | DECAYED = 2 |
static const int | HISTORY = 3 |
static const int | X_AXIS = 1 |
static const int | Y_AXIS = 2 |
static const int | Z_AXIS = 3 |
static const int | Z0 = 23 |
static const int | HIGGS = 25 |
static const int | HIGGS_A = 36 |
static const int | HIGGS_PLUS = 37 |
static const int | HIGGS_MINUS = -37 |
static const int | W_PLUS = 24 |
static const int | W_MINUS = -24 |
static const int | GAMMA = 22 |
static const int | TAU_PLUS = -15 |
static const int | TAU_MINUS = 15 |
static const int | TAU_NEUTRINO = 16 |
static const int | TAU_ANTINEUTRINO = -16 |
static const int | MUON_PLUS = -13 |
static const int | MUON_MINUS = 13 |
static const int | MUON_NEUTRINO = 14 |
static const int | MUON_ANTINEUTRINO = -14 |
static const int | POSITRON = -11 |
static const int | ELECTRON = 11 |
static const int | ELECTRON_NEUTRINO = 12 |
static const int | ELECTRON_ANTINEUTRINO = -12 |
static const int | UP = 2 |
static const int | ANTIUP = -2 |
static const int | DOWN = 1 |
static const int | ANTIDOWN = -1 |
static const int | GLUON = 21 |
static const int | CHARM = 4 |
static const int | TOP = 6 |
static const int | STRANGE = 3 |
static const int | BOTTOM = 5 |
static const int | OTHER = 0 |
Private Attributes | |
TauolaHEPEVTEvent * | m_event |
int | m_barcode |
int | m_first_mother |
int | m_second_mother |
int | m_daughter_start |
int | m_daughter_end |
int | m_pdgid |
int | m_status |
double | m_px |
double | m_py |
double | m_pz |
double | m_e |
double | m_generated_mass |
vector< TauolaHEPEVTParticle * > | cache |
Definition at line 30 of file TauolaHEPEVTParticle.h.
~TauolaHEPEVTParticle | ( | ) |
Default destructor
Definition at line 8 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::cache, and TauolaHEPEVTParticle::m_barcode.
TauolaHEPEVTParticle | ( | int | pdgid, | |
int | status, | |||
double | px, | |||
double | py, | |||
double | pz, | |||
double | e, | |||
double | m, | |||
int | ms, | |||
int | me, | |||
int | ds, | |||
int | de | |||
) |
Default constructor
Definition at line 16 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_barcode, TauolaHEPEVTParticle::m_daughter_start, TauolaHEPEVTParticle::m_event, TauolaHEPEVTParticle::m_first_mother, TauolaHEPEVTParticle::m_generated_mass, TauolaHEPEVTParticle::m_pdgid, TauolaHEPEVTParticle::m_px, and TauolaHEPEVTParticle::m_status.
void add | ( | TauolaParticle * | other_particle | ) | [inherited] |
Add the 4 momentum of another particle to this particle
Definition at line 44 of file TauolaParticle.cxx.
References TauolaParticle::getE(), TauolaParticle::getPx(), TauolaParticle::getPy(), TauolaParticle::getPz(), TauolaParticle::setE(), TauolaParticle::setMass(), TauolaParticle::setPx(), TauolaParticle::setPy(), and TauolaParticle::setPz().
void addDecayToEventRecord | ( | ) | [inherited] |
Invokes TAUOLA FORTRAN routine DEKAY retrieving the daughters of decayed tau.
Definition at line 109 of file TauolaParticle.cxx.
References DecayList::addToEnd(), TauolaParticle::boostAlongZ(), DecayList::clear(), TauolaParticle::clone(), Log::Fatal(), TauolaParticle::getE(), TauolaParticle::getP(), DecayList::getParticle(), TauolaParticle::getPdgID(), TauolaParticle::getPx(), TauolaParticle::getPy(), TauolaParticle::getPz(), TauolaParticle::getSign(), TauolaParticle::hasDaughters(), Tauolapp::TauolaWriteDecayToEventRecord(), and TauolaParticle::Z_AXIS.
void boostAlongZ | ( | double | boost_pz, | |
double | boost_e | |||
) | [inherited] |
Do a Lorenz transformation along the Z axis.
Boost this vector along the Z direction. Assume no momentum components in the X or Y directions.
Definition at line 292 of file TauolaParticle.cxx.
References TauolaParticle::getE(), TauolaParticle::getPz(), TauolaParticle::setE(), and TauolaParticle::setPz().
void boostDaughtersToRestFrame | ( | TauolaParticle * | boost | ) | [inherited] |
Transform the four momentum of all the daughters recursively into the frame of the "particle" TauolaParticle.
Definition at line 215 of file TauolaParticle.cxx.
References TauolaParticle::getDaughters(), and TauolaParticle::hasDaughters().
void boostFromRestFrame | ( | TauolaParticle * | boost | ) | [inherited] |
Transform this particles four momentum from the rest frame of the paramter TauolaParticle, back into the lab frame.
Definition at line 250 of file TauolaParticle.cxx.
References TauolaParticle::boostAlongZ(), TauolaParticle::getE(), TauolaParticle::getP(), TauolaParticle::getRotationAngle(), TauolaParticle::rotate(), TauolaParticle::X_AXIS, and TauolaParticle::Y_AXIS.
void boostToRestFrame | ( | TauolaParticle * | boost | ) | [inherited] |
Transform this particles four momentum from the lab frome into the rest frame of the paramter TauolaParticle.
Definition at line 234 of file TauolaParticle.cxx.
References TauolaParticle::boostAlongZ(), TauolaParticle::getE(), TauolaParticle::getP(), TauolaParticle::getRotationAngle(), TauolaParticle::rotate(), TauolaParticle::X_AXIS, and TauolaParticle::Y_AXIS.
void checkMomentumConservation | ( | ) | [virtual] |
Check that the 4 momentum in conserved in the decay of this particle
Reimplemented from TauolaParticle.
Definition at line 141 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::getE(), TauolaHEPEVTParticle::getFirstMotherIndex(), TauolaHEPEVTEvent::getParticle(), TauolaHEPEVTParticle::getPx(), TauolaHEPEVTParticle::getPy(), TauolaHEPEVTParticle::getPz(), TauolaHEPEVTParticle::getSecondMotherIndex(), TauolaHEPEVTParticle::m_daughter_start, TauolaHEPEVTParticle::m_event, TauolaHEPEVTParticle::print(), Log::RedirectOutput(), and Log::RevertOutput().
TauolaParticle * clone | ( | ) | [inherited] |
Create a new particle with the same properties as this one. Mothers and daughters will not be linked.
Definition at line 21 of file TauolaParticle.cxx.
References TauolaParticle::createNewParticle(), TauolaParticle::getE(), TauolaParticle::getMass(), TauolaParticle::getPdgID(), TauolaParticle::getPx(), TauolaParticle::getPy(), TauolaParticle::getPz(), and TauolaParticle::getStatus().
TauolaHEPEVTParticle * createNewParticle | ( | int | pdg_id, | |
int | status, | |||
double | mass, | |||
double | px, | |||
double | py, | |||
double | pz, | |||
double | e | |||
) | [virtual] |
Creates a new particle of type TauolaHEPEVTParticle, with the given properties. The new particle bares no relations to this particle, but `this particle' provides only a way of creating an instance of this derived class. eg. createNewParticle() is used inside filhep_() so that a TauolaHEPEVTParticle can be created without the method having explicit knowledge of the TauolaHEPEVTParticle class
Implements TauolaParticle.
Definition at line 196 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::cache, and TauolaHEPEVTParticle::TauolaHEPEVTParticle().
void decay | ( | ) | [inherited] |
Decay the particle. This calls the decay methods in the interface to (FORTRAN) tauola.
Definition at line 103 of file TauolaParticle.cxx.
References TauolaParticle::getSign(), TauolaParticle::m_pol_n, TauolaParticle::m_pol_x, TauolaParticle::m_pol_y, TauolaParticle::m_pol_z, and Tauolapp::TauolaDecay().
virtual void decayEndgame | ( | ) | [inline, virtual, inherited] |
Optional. Modify particle or decay tree if needed.
Reimplemented in TauolaHepMCParticle.
Definition at line 261 of file TauolaParticle.h.
TauolaParticle * findLastSelf | ( | ) | [inherited] |
Traverse the event structure and find the final version of this particle which does not have a particle of it's own type as it's daughter. eg. Generally the final stable copy
Definition at line 78 of file TauolaParticle.cxx.
References TauolaParticle::getDaughters(), and TauolaParticle::getPdgID().
std::vector< TauolaParticle * > findProductionMothers | ( | ) | [inherited] |
Traverse the event structure and find the first set of mothers which are not of the same type as this particle.
Definition at line 91 of file TauolaParticle.cxx.
References TauolaParticle::getMothers(), and TauolaParticle::getPdgID().
double getAngle | ( | TauolaParticle * | other_particle | ) | [inherited] |
Get the angle between this particle and another particle
Definition at line 29 of file TauolaParticle.cxx.
References TauolaParticle::getPx(), TauolaParticle::getPy(), and TauolaParticle::getPz().
int getBarcode | ( | ) | [virtual] |
Get the barcode (position in list) of this particle
Implements TauolaParticle.
Definition at line 291 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_barcode.
int getDaughterRangeEnd | ( | ) |
Get index of last daughter
Definition at line 315 of file TauolaHEPEVTParticle.cxx.
int getDaughterRangeStart | ( | ) |
Get index of first daughter
Definition at line 311 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_daughter_start.
std::vector< TauolaParticle * > getDaughters | ( | ) | [virtual] |
Returns the daughters of this particle via a vector of TauolaParticle
Implements TauolaParticle.
Definition at line 94 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTEvent::getParticle(), TauolaHEPEVTEvent::getParticleCount(), TauolaHEPEVTParticle::isDaughterOf(), TauolaHEPEVTParticle::m_daughter_start, TauolaHEPEVTParticle::m_event, and TauolaHEPEVTParticle::m_status.
double getE | ( | ) | [virtual] |
Returns the energy component of the four vector
Implements TauolaParticle.
Definition at line 270 of file TauolaHEPEVTParticle.cxx.
int getFirstMotherIndex | ( | ) |
Get index of first mother
Definition at line 303 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_first_mother.
double getMass | ( | ) |
Get the mass stored (i.e. not calculated from four vector) at generation step
Reimplemented from TauolaParticle.
Definition at line 254 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_generated_mass.
std::vector< TauolaParticle * > getMothers | ( | ) | [virtual] |
Returns the mothers of this particle via a vector of TauolaParticle
Implements TauolaParticle.
Definition at line 76 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTEvent::getParticle(), TauolaHEPEVTParticle::m_event, and TauolaHEPEVTParticle::m_first_mother.
double getP | ( | int | axis | ) | [inherited] |
Get momentum component in the direction of "axis" (x,y,z)
Definition at line 343 of file TauolaParticle.cxx.
References TauolaParticle::getPx(), TauolaParticle::getPy(), TauolaParticle::getPz(), TauolaParticle::X_AXIS, TauolaParticle::Y_AXIS, and TauolaParticle::Z_AXIS.
double getP | ( | ) | [inherited] |
Get scalar momentum
Definition at line 339 of file TauolaParticle.cxx.
References TauolaParticle::getPx(), TauolaParticle::getPy(), and TauolaParticle::getPz().
int getPdgID | ( | ) | [virtual] |
Get the PDG ID code of this particle
Implements TauolaParticle.
Definition at line 246 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_pdgid.
double getPolarimetricX | ( | ) | [inherited] |
Get the polarimetric vector of this particle in the direction X. (Only relevant for tau particles).
Definition at line 8 of file TauolaParticle.cxx.
References TauolaParticle::m_pol_x.
double getPolarimetricY | ( | ) | [inherited] |
Get the polarimetric vector of this particle in the direction Y. (Only relevant for tau particles).
Definition at line 12 of file TauolaParticle.cxx.
References TauolaParticle::m_pol_y.
double getPolarimetricZ | ( | ) | [inherited] |
Get the polarimetric vector of this particle in the direction Z. (Only relevant for tau particles).
Definition at line 16 of file TauolaParticle.cxx.
References TauolaParticle::m_pol_z.
double getPx | ( | ) | [inline, virtual] |
Returns the px component of the four vector
Implements TauolaParticle.
Definition at line 258 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_px.
double getPy | ( | ) | [inline, virtual] |
Returns the py component of the four vector
Implements TauolaParticle.
Definition at line 262 of file TauolaHEPEVTParticle.cxx.
double getPz | ( | ) | [virtual] |
Returns the pz component of the four vector
Implements TauolaParticle.
Definition at line 266 of file TauolaHEPEVTParticle.cxx.
double getRotationAngle | ( | int | axis, | |
int | second_axis = Z_AXIS | |||
) | [inherited] |
Returns the angle around the axis "axis" needed to rotate the four momenum is such a way that the non-Z component disappears and Z>0. This is used to rotating the coordinate system into a frame with only a Z component before calling boostAlongZ().
Get the angle needed to rotate the 4 momentum vector so that the x (y) component disapears. (and the Z component is > 0)
if(getP(axis)==0){ if(getPz()>0) return 0; //no rotaion required else return M_PI; }
Definition at line 269 of file TauolaParticle.cxx.
References TauolaParticle::getP().
int getSecondMotherIndex | ( | ) |
Get index of second mother
Definition at line 307 of file TauolaHEPEVTParticle.cxx.
int getSign | ( | ) | [inherited] |
Get whether this particle has the same or opposite sign to the pdg code given to the Tauola object. (Only relevant for tau particles).
Definition at line 62 of file TauolaParticle.cxx.
References Tauola::getDecayingParticle(), TauolaParticle::getPdgID(), TauolaParticle::NA_SIGN, TauolaParticle::OPPOSITE_SIGN, and TauolaParticle::SAME_SIGN.
int getStatus | ( | ) | [virtual] |
Get the status of this particle
Implements TauolaParticle.
Definition at line 250 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_status.
bool hasDaughters | ( | ) | [inherited] |
Return whether the particle has any chidren
Definition at line 71 of file TauolaParticle.cxx.
References TauolaParticle::getDaughters().
bool isDaughterOf | ( | TauolaHEPEVTParticle * | p | ) |
Check if particle 'p' is daughter of this particle
Definition at line 207 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::getBarcode(), and TauolaHEPEVTParticle::m_first_mother.
bool isMotherOf | ( | TauolaHEPEVTParticle * | p | ) |
Check if particle 'p' is mother of this particle
Definition at line 215 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::getBarcode(), and TauolaHEPEVTParticle::m_daughter_start.
void print | ( | ) | [virtual] |
Print information on this particle into standard output
Implements TauolaParticle.
Definition at line 223 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_barcode, TauolaHEPEVTParticle::m_daughter_start, TauolaHEPEVTParticle::m_first_mother, TauolaHEPEVTParticle::m_generated_mass, TauolaHEPEVTParticle::m_pdgid, TauolaHEPEVTParticle::m_px, and TauolaHEPEVTParticle::m_status.
void rotate | ( | int | axis, | |
double | theta, | |||
int | second_axis = Z_AXIS | |||
) | [inherited] |
rotate this particles 4-momentum by an angle phi from the axisis "axis" towards the axis "second_axis".
Rotation around an axis X or Y
Definition at line 305 of file TauolaParticle.cxx.
References TauolaParticle::getP(), and TauolaParticle::setP().
void setBarcode | ( | int | barcode | ) |
Set barcode (position in list) of this particle
Definition at line 295 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_barcode.
void setDaughters | ( | std::vector< TauolaParticle * > | daughters | ) | [virtual] |
Set the daughters of this particle via a vector of TauolaParticle
Implements TauolaParticle.
Definition at line 56 of file TauolaHEPEVTParticle.cxx.
References Log::Fatal(), TauolaHEPEVTParticle::m_daughter_start, and TauolaHEPEVTParticle::m_event.
void setE | ( | double | e | ) | [virtual] |
Set the energy component of the four vector
Implements TauolaParticle.
Definition at line 287 of file TauolaHEPEVTParticle.cxx.
void setEvent | ( | TauolaHEPEVTEvent * | event | ) |
Set event of this particle
Definition at line 299 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_event.
void setMass | ( | double | mass | ) | [virtual] |
Set the mass of this particle
Implements TauolaParticle.
Definition at line 242 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_generated_mass.
void setMothers | ( | std::vector< TauolaParticle * > | mothers | ) | [virtual] |
Set the mothers of this particle via a vector of TauolaParticle
Implements TauolaParticle.
Definition at line 40 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTEvent::addParticle(), Log::Fatal(), TauolaHEPEVTParticle::getBarcode(), TauolaHEPEVTParticle::m_barcode, and TauolaHEPEVTParticle::m_first_mother.
void setP | ( | int | axis, | |
double | p_component | |||
) | [inherited] |
Set momentum component in the direction of "axis" (x,y,z)
Definition at line 356 of file TauolaParticle.cxx.
References TauolaParticle::setPx(), TauolaParticle::setPy(), TauolaParticle::setPz(), TauolaParticle::X_AXIS, TauolaParticle::Y_AXIS, and TauolaParticle::Z_AXIS.
void setPdgID | ( | int | pdg_id | ) | [virtual] |
Set the PDG ID code of this particle
Implements TauolaParticle.
Definition at line 234 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_pdgid.
void setPx | ( | double | px | ) | [virtual] |
Set the px component of the four vector
Implements TauolaParticle.
Definition at line 274 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_px.
void setPy | ( | double | py | ) | [virtual] |
Set the px component of the four vector
Implements TauolaParticle.
Definition at line 278 of file TauolaHEPEVTParticle.cxx.
void setPz | ( | double | pz | ) | [virtual] |
Set the pz component of the four vector
Implements TauolaParticle.
Definition at line 283 of file TauolaHEPEVTParticle.cxx.
void setStatus | ( | int | statu | ) | [virtual] |
Set the status of this particle
Implements TauolaParticle.
Definition at line 238 of file TauolaHEPEVTParticle.cxx.
References TauolaHEPEVTParticle::m_status.
void subtract | ( | TauolaParticle * | other_particle | ) | [inherited] |
Subtract the 4 momentum of another particle from this particle
Definition at line 53 of file TauolaParticle.cxx.
References TauolaParticle::getE(), TauolaParticle::getPx(), TauolaParticle::getPy(), TauolaParticle::getPz(), TauolaParticle::setE(), TauolaParticle::setMass(), TauolaParticle::setPx(), TauolaParticle::setPy(), and TauolaParticle::setPz().
void undecay | ( | ) | [virtual] |
Remove the decay branch from the event record and reset the particle status code to stable. WARNING: not implemented for HEPEVT.
Reimplemented from TauolaParticle.
Definition at line 35 of file TauolaHEPEVTParticle.cxx.
const int ANTIDOWN = -1 [static, inherited] |
anti-down quark
Definition at line 142 of file TauolaParticle.h.
const int ANTIUP = -2 [static, inherited] |
anti-up quark
Definition at line 136 of file TauolaParticle.h.
vector<TauolaHEPEVTParticle*> cache [private] |
List of created particles - if they are not in the event, they will be deleted when no longer needed
Definition at line 169 of file TauolaHEPEVTParticle.h.
const int DECAYED = 2 [static, inherited] |
Decayed particle status
Definition at line 55 of file TauolaParticle.h.
const int DOWN = 1 [static, inherited] |
down quark
Definition at line 139 of file TauolaParticle.h.
const int ELECTRON = 11 [static, inherited] |
e- particle
Definition at line 124 of file TauolaParticle.h.
const int ELECTRON_ANTINEUTRINO = -12 [static, inherited] |
e antineutrino particle
Definition at line 130 of file TauolaParticle.h.
const int ELECTRON_NEUTRINO = 12 [static, inherited] |
e neutrino particle
Definition at line 127 of file TauolaParticle.h.
const int GAMMA = 22 [static, inherited] |
photon
Definition at line 92 of file TauolaParticle.h.
const int HIGGS = 25 [static, inherited] |
H particle
Definition at line 73 of file TauolaParticle.h.
const int HIGGS_A = 36 [static, inherited] |
A0 particle
Definition at line 76 of file TauolaParticle.h.
const int HIGGS_MINUS = -37 [static, inherited] |
H- particle
Definition at line 82 of file TauolaParticle.h.
const int HIGGS_PLUS = 37 [static, inherited] |
H+ particle
Definition at line 79 of file TauolaParticle.h.
const int HISTORY = 3 [static, inherited] |
History particle status
Definition at line 58 of file TauolaParticle.h.
int m_barcode [private] |
Position in the event record
Definition at line 147 of file TauolaHEPEVTParticle.h.
int m_daughter_start [private] |
Range of indexes of daughters (-1 if do not have daughters)
Definition at line 153 of file TauolaHEPEVTParticle.h.
TauolaHEPEVTEvent* m_event [private] |
Event from which this particle is taken
Definition at line 144 of file TauolaHEPEVTParticle.h.
int m_first_mother [private] |
Indexes of mothers (-1 if do not have mothers)
Definition at line 150 of file TauolaHEPEVTParticle.h.
double m_generated_mass [private] |
Mass saved at generation step
Definition at line 165 of file TauolaHEPEVTParticle.h.
int m_pdgid [private] |
PDG ID
Definition at line 156 of file TauolaHEPEVTParticle.h.
double m_px [private] |
Momentum
Definition at line 162 of file TauolaHEPEVTParticle.h.
int m_status [private] |
Status (stable, decayed)
Definition at line 159 of file TauolaHEPEVTParticle.h.
const int MUON_ANTINEUTRINO = -14 [static, inherited] |
muon antineutrino particle
Definition at line 117 of file TauolaParticle.h.
const int MUON_MINUS = 13 [static, inherited] |
muon- particle
Definition at line 111 of file TauolaParticle.h.
const int MUON_NEUTRINO = 14 [static, inherited] |
muon neutrino particle
Definition at line 114 of file TauolaParticle.h.
const int MUON_PLUS = -13 [static, inherited] |
muon+ particle
Definition at line 108 of file TauolaParticle.h.
const int NA_SIGN = 3 [static, inherited] |
Sign type is not applicable for this particle (probably it's not a tau).
Definition at line 49 of file TauolaParticle.h.
const int OPPOSITE_SIGN = 2 [static, inherited] |
The opposite sign to decaying particle pdg ID code given to Tauola object (only meaningful for taus).
Definition at line 45 of file TauolaParticle.h.
const int OTHER = 0 [static, inherited] |
All other particle types
Definition at line 151 of file TauolaParticle.h.
const int POSITRON = -11 [static, inherited] |
e+ particle
Definition at line 121 of file TauolaParticle.h.
const int SAME_SIGN = 1 [static, inherited] |
The same sign as decaying particle pdg ID code given to Tauola object (only meaningful for taus).
Definition at line 41 of file TauolaParticle.h.
const int STABLE = 1 [static, inherited] |
Stable particle status
Definition at line 52 of file TauolaParticle.h.
const int TAU_ANTINEUTRINO = -16 [static, inherited] |
tau antineutrino particle
Definition at line 104 of file TauolaParticle.h.
const int TAU_MINUS = 15 [static, inherited] |
tau- particle
Definition at line 98 of file TauolaParticle.h.
const int TAU_NEUTRINO = 16 [static, inherited] |
tau neutrino particle
Definition at line 101 of file TauolaParticle.h.
const int TAU_PLUS = -15 [static, inherited] |
tau+ particle
Definition at line 95 of file TauolaParticle.h.
const int UP = 2 [static, inherited] |
up quark
Definition at line 133 of file TauolaParticle.h.
const int W_MINUS = -24 [static, inherited] |
W- particle
Definition at line 89 of file TauolaParticle.h.
const int W_PLUS = 24 [static, inherited] |
W+ particle
Definition at line 86 of file TauolaParticle.h.
const int X_AXIS = 1 [static, inherited] |
X Axis
Definition at line 61 of file TauolaParticle.h.
const int Y_AXIS = 2 [static, inherited] |
Y Axis
Definition at line 64 of file TauolaParticle.h.
const int Z0 = 23 [static, inherited] |
Z0 particle
Definition at line 70 of file TauolaParticle.h.
const int Z_AXIS = 3 [static, inherited] |
Z Axis
Definition at line 67 of file TauolaParticle.h.
